ISUZU GIGA (6X2) FVM RIGID

Isuzu GIGA FVM 6x2 Rigid all type,bisa muatan banyak,tangguh dijalanan dan tanjakan,irit bahan bakar,heavy duty commonrail,radio/cd/mp3,kamera mundu

Rp. 940.000.000

4 Rating
Category : Medium Truck

Type Product

Type Name Price Product Description
FVM N 245 PS Rp. 931.000.000 HARGA OFF THE ROAD MESIN EURO 4
FVM U 245 PS Rp. 2.147.483.647 HARGA OFF THE ROAD MESIN EURO 4
FVM U HP 285 PS Rp. 996.000.000 HARGA OFF THE ROAD MESIN EURO 4
FVM N HP ABS 285 PS Rp. 1.012.000.000 HARGA OFF THE ROAD MESIN EURO 4
  Call Sales

Product Spesification

DIMENSI
  Panjang Keseluruhan : 11,945 (mm)
  Lebar Keseluruhan : 2,485 (mm)
  Tinggi Keseluruhan : 2,965 (mm)
  Jarak Terendah : 260 (mm)
  Jarak Sumbu : 5,825 + 1,370 (mm)
  Jarak Pijak Roda Depan : 2,060 (mm)
  Jarak Pijak Roda Belakang : 1,850 (mm)
  Julur Depan Front Over Hang(FOH) : 1,250 (mm)
  Julur Belakang Rear Over Hang(ROH) : 3,500 (mm)
  Seating Capacity : - (person)
  Front Axle Capacity : 6,000 (kg)
  Rear Axle Capacity : 20,000 (kg)
MESIN
  Model/Tipe : 6HK1-TCS
  Sistem injeksi bahan bakar : In-line 6 Cylinders, OHC, Direction Injection Diesel
  Isi silinder : 7,790 (cc)
  Tenaga maksimum : 285/2400 (PS/rpm)
  Torsi maksimum : 80.5/1450-2400 (Kgm/rpm)
  Garis tengah x langkah : 115x125 (mm)
  Radius Putar : 10,8 (m)
BAN & VELG
  Ban Depan : Single 10.00-20-16PR Miller
  Ban Belakang : Double 10.00-20-16PR Miller
  Velg : 10 STUD 20 x 7.50 T
BERAT
  Curb Weight (berat kosong) : 7,350 (kg)
  Gross Vehicle Weight (berat total) : 26,000 (kg)
TRANSMISI
  Model : ES11109DD ( Double H )
  C :
  gigi 1 : 12.638
  gigi 2 : 8.807
  gigi 3 : 6.550
  gigi 4 : 4.768
  gigi 5 : 3.548
  gigi 6 : 2.482
  gigi 7 : 1.846
  gigi 8 : 1.344
  gigi 9 :
  Rev : 13.210
  Final Gear Ratio : 5.857
REM
  Service brake : Full Air
  Parking brake : Full Air
  Exhaust brake : Full Air
  Control Rem : -
LAIN-LAIN
  Seat belt : Ada
  Accu : - (V-AH)
  Alternator : 24-60 (V-A)
  Kapasitas Tangki : 200 (liter)
  Max. Gradeability : 43 (%)
  Max. Speed : 94 (Km/h)
  Clutch Diameter : 380 (mm)
